Silicone Spiral Tubing

Silicone Spiral Tubing

CUSTUMIZATION AVAILABLE AS PER REQUIRMENT.

Inquire Now Catalogue
  • More Info

Application :

  • Medical Equipment tubing.
  • Food processing equipment.
  • Pharmaceutical Industries

Key Features :

  • Resistance to UV and Ozone.
  • Harmless toxic and physiological effect to humans.
  • Free of Bacterial growth.
  • Odorless & Test-less.
  • Superiors/High Tear Strength.
  • High & Low Temperature Rating -40°C to -200°C (normal).
  • Customize Size and Color Available.

Technical Data :

Physical Properties Test Method Units Typical Values
Specific Gravity DIN EN ISO 1183-1 A g/cm3 1.1
Hardness, Shore A D2240 SHORE A 80±5
Tensile strength psi(Mpa) D412 MPA 7
Elongation (%) D412 % 215
Tear Resistance, Die B lbf./in. (KN/m) D624 KN/M 17
Tensile Modulus @100%psi(Mpa) - - -
Temperature Rating - °C -40 TO 220
Compression set 22h@175°C ASTM D395 method B % 16
